产品名称:

ARP690-P8
ARP690-P8
ARP690-P8
ARP690-P8
ARP690-P8

产品简介:

型号:ARP690

便携式工作站机箱, 21.5' LCD , 1920x 1080, 可安装ATX主机板, 提供7个全长扩充槽,各国语言键盘和触控板, SFX 750W电源供应器(电源可选配), 10x 3.5', 及 5x 5.25'盘位可选,超薄DVD光驱盘位, 航空软包。

  • Features
  • Specifications
  • Environmental Factors
  • Ordering Information
  • Aluminum Construction with shock absorbing rubber corners

  • 21.5' LCD display support Full HD, 1920x 1080 resolution, Anti-reflection tempered glass

  • Support Standard ATX Motherboard, EATX MB (10x 3.5' Model)

  • Offer 7-slot expansion capability

  • SFX 750W power supply, 100~240VAC

  • Offer 10x 3.5', 1x slim DVD-RW drive bay, Option: 6x 5.25', 1x slim DVD-RW

  • Industrial multi-language Keyboard with touchpad

  • Keyboard is integrated with the portable to allow closing against the portable for both convenience and protection in transportation

  • Large handle provide convenience transportation of the portable with comfort and ease

  • Trolley case to manage portable PC with ease


Model NoARP690-P8
Motherboard

Support Standard ATX Motherboard (Support up to 12'x 12' MB)

Support Extended ATX MB (10x 3.5' Model)

Slots

Offer 7 expansion slots

Display

21.5' LCD display, 1920x 1080 resolution

Anti-reflection tempered strengthen glass

Drive bay10x 3.5', 1x slim DVD-RW (Option: 6x 5.25', 1x slim DVD-RW)
VGAAD conversion board, DisplayPort interface (Option DVI or VGA)
KB/MS

Industrial keyboard with touchpad, Operating life of keys: 8 million cycles

Option KB: CH, FRGRITJPKRPTRUSPUKUS

Power Supply

SFX 750W, 100~240VAC, Auto switch

ConstructionAluminum Construction with shock absorbing rubber corners
SpeakerBuilt-in amplified 2x 3W speakers
Dimension524Wx 372Hx 226D mm
Weight15 kgs
Trolley CasePadded Trolley case with wheels




OperatingNon-Operating
Temperature0°C~50°C-20°C~60°C
Relative Humidity10%~90%10%~95%


ARP690-P8      ARP690-P8


Product No.Description
ARP690-P21USAP8

21.5' LCD, 7 slots, 10x 3.5', 1x slim DVD-RW drive bay, SFX 750W, DP, Trolley case

ARP690-P21USAD8

21.5' LCD, 7 slots, 10x 3.5', 1x slim DVD-RW drive bay, SFX 750W, DVI, Trolley case

ARP690-P21USA8

21.5' LCD, 7 slots, 10x 3.5', 1x slim DVD-RW drive bay, SFX 750W, VGA, Trolley case

ARP690-P21USBP821.5' LCD, 7 slots, 6x 5.25', 1x slim DVD-RW drive bay, SFX 750W, DP, Trolley case
ARP690-P21USBD821.5' LCD, 7 slots, 6x 5.25', 1x slim DVD-RW drive bay, SFX 750W, DVI, Trolley case
ARP690-P21USB821.5' LCD, 7 slots, 6x 5.25', 1x slim DVD-RW drive bay, SFX 750W, VGA, Trolley case

Option:

Touch screen (Resistive)

Sunlight readable (1000 nits)

Keyboard layout: CH, FR, GR, KR, RU, SP, UK, US
